Model
|
HY1010
|
HY1210
|
HY1510
|
HY1810
|
|
MECHANICAL
SPECIFICATIONS
|
|
|
|
|
|
Overall diameter
|
mm
|
260
|
313
|
393
|
460
|
|
Bolt circle diameter
|
mm
|
246
|
296
|
374
|
441
|
|
Baffle cutout
diameter
|
mm
|
235
|
284
|
353
|
423
|
|
Depth
|
mm
|
102
|
121
|
149
|
182
|
|
Flange and Gasket
|
mm
|
12
|
13
|
15
|
15
|
|
Net weight
|
kg
|
2.6
|
4.9
|
9.8
|
11.5
|
|
Shipping box (single
carton box)
|
mm
|
290*290*160
|
340*340*170
|
425*425*200
|
495*495*235
|
|
ELECTRICAL
SPECIFICATIONS
|
|
|
|
|
|
Nominal
diameter
|
inch
|
10
|
12
|
15
|
18
|
|
Nominal impedance
|
Ω
|
8
|
8
|
8
|
8
|
|
DC resistance
|
Ω
|
5.2
|
5.2
|
5.2
|
5.2
|
|
Nominal power
handling (AES)
|
W
|
250
|
400
|
600
|
800
|
|
Program power handling
|
W
|
500
|
800
|
1200
|
1600
|
|
Sensitivity
(1W/1m)
|
±
2dB
|
94
|
94
|
96
|
96
|
|
Frequency range
(-10dB max)
|
Hz
|
45-4.5K
|
40-4K
|
35-3.5K
|
30-3K
|
|
Voice coil diameter
|
mm
|
50， 2inch
|
75， 3inch
|
100， 4inch
|
100，4inch
|
|
Voice coil material
|
cu
|
EISV
|
AP
|
AP
|
AP
|
|
Former material
|
|
Kapton
|
TIL
|
TIL
|
TIL
|
|
Winding depth
|
mm
|
13.5
|
16
|
20
|
20
|
|
Plate
|
mm
|
8
|
8
|
10
|
10
|
|
Magnet
|
oz
|
40
|
60
|
100
|
125
|
|
Basket
|
|
Aluminium
|
Aluminium
|
Aluminium
|
Aluminium
|
|
THIELE
& SMALL PARAMETERS
|
|
|
|
|
|
Fo
|
|
|
Hz
|
53
|
48
|
46
|
35.8
|
|
Revc
|
Ω
|
5.2
|
5.2
|
5.2
|
5.2
|
|
Sd
|
M2
|
0.034
|
0.054
|
0.083
|
0.125
|
|
Vas
|
L
|
49
|
62.5
|
114
|
242
|
|
Cms
|
uM/N
|
289
|
156
|
107
|
108
|
|
Mms
|
g
|
30
|
70
|
107
|
182
|
|
Bl
|
Tm
|
10.3
|
14.9
|
18.2
|
20.3
|
|
Qms
|
|
12.9
|
15
|
10.7
|
10.5
|
|
Qes
|
|
0.54
|
0.55
|
0.47
|
0.52
|
|
Qts
|
|
0.52
|
0.53
|
0.45
|
0.5
|
|
Levc
|
mH
|
0.22
|
0.36
|
0.65
|
0.65
|
|
No
|
|
1.35%
|
1.19%
|
2.39%
|
2.04%
|
