Model
|
HY1206
|
HY1506
|
HY1806
|
|
MECHANICAL
SPECIFICATIONS
|
|
|
|
|
Overall diameter
|
mm
|
320
|
395
|
465
|
|
Bolt circle diameter
|
mm
|
301
|
372
|
445
|
|
Baffle cutout
diameter
|
mm
|
283
|
355
|
422
|
|
Depth
|
mm
|
130
|
152
|
185
|
|
Flange and Gasket
|
mm
|
12
|
21
|
14
|
|
Net weight
|
kg
|
6.3
|
11.2
|
11.6
|
|
Shipping box (single
carton box)
|
mm
|
345*345*175
|
420*420*195
|
495*495*235
|
|
ELECTRICAL
SPECIFICATIONS
|
|
|
|
|
Nominal
diameter
|
inch
|
12
|
15
|
18
|
|
Nominal impedance
|
Ω
|
8
|
8
|
8
|
|
DC resistance
|
Ω
|
5.5
|
5.3
|
5.3
|
|
Nominal power
handling (AES)
|
W
|
400
|
600
|
800
|
|
Program power handling
|
W
|
800
|
1200
|
1600
|
|
Sensitivity
(1W/1m)
|
±
2dB
|
95
|
95
|
96
|
|
Frequency range
(-10dB max)
|
Hz
|
45-3.5K
|
35-3K
|
30-3K
|
|
Voice coil diameter
|
mm
|
75, 3inch
|
100, 4inch
|
100, 4inch
|
|
Voice coil material
|
cu
|
AP
|
AP
|
AP
|
|
Former material
|
|
TIL
|
TIL
|
TIL
|
|
Winding depth
|
mm
|
17.5
|
20
|
20
|
|
Plate
|
mm
|
8
|
10
|
10
|
|
Magnet
|
oz
|
78
|
125
|
125
|
|
Basket
|
|
Aluminium
|
Aluminium
|
Aluminium
|
|
THIELE
& SMALL PARAMETERS
|
|
|
|
|
Fo
|
|
|
Hz
|
60
|
48
|
35
|
|
Revc
|
Ω
|
5.2
|
5.3
|
5.3
|
|
Sd
|
M2
|
0.053
|
0.088
|
0.145
|
|
Vas
|
L
|
37.8
|
59
|
228
|
|
Cms
|
uM/N
|
94
|
53
|
107
|
|
Mms
|
g
|
68
|
119
|
184
|
|
Bl
|
Tm
|
18.7
|
19.8
|
19.8
|
|
Qms
|
|
10.9
|
8.3
|
8
|
|
Qes
|
|
0.395
|
0.65
|
0.62
|
|
Qts
|
|
0.38
|
0.6
|
0.58
|
|
Levc
|
mH
|
0.41
|
0.81
|
0.79
|
|
No
|
|
2.20%
|
2.20%
|
1.60%
|
