Model
|
HY1513
|
HY1813
|
|
MECHANICAL
SPECIFICATIONS
|
|
|
|
Overall diameter
|
mm
|
388
|
475
|
|
Bolt circle diameter
|
mm
|
371
|
450
|
|
Baffle cutout
diameter
|
mm
|
355
|
424
|
|
Depth
|
mm
|
125
|
182
|
|
Flange and Gasket
|
mm
|
15
|
15
|
|
Net weight
|
kg
|
9.4
|
11.3
|
|
Shipping box (single
carton box)
|
mm
|
420*420*175
|
510*510*230
|
|
ELECTRICAL
SPECIFICATIONS
|
|
|
|
Nominal
diameter
|
inch
|
15
|
18
|
|
Nominal impedance
|
Ω
|
8
|
8
|
|
DC resistance
|
Ω
|
5.2
|
5.2
|
|
Nominal power
handling (AES)
|
W
|
600
|
800
|
|
Program power handling
|
W
|
1200
|
1600
|
|
Sensitivity
(1W/1m)
|
±
2dB
|
94
|
96
|
|
Frequency range
(-10dB max)
|
Hz
|
35-3.0K
|
30-3.0K
|
|
Voice coil diameter
|
mm
|
100， 4inch
|
100，4inch
|
|
Voice coil material
|
cu
|
AP
|
AP
|
|
Former material
|
|
TIL
|
TIL
|
|
Winding depth
|
mm
|
20
|
20
|
|
Plate
|
mm
|
10
|
10
|
|
Magnet
|
oz
|
100
|
125
|
|
Basket
|
|
Aluminium
|
Aluminium
|
|
THIELE & SMALL PARAMETERS
|
|
|
|
Fo
|
|
|
Hz
|
52
|
40
|
|
Revc
|
Ω
|
5.8
|
5.8
|
|
Sd
|
M2
|
0.088
|
0.13
|
|
Vas
|
L
|
71
|
178
|
|
Cms
|
uM/N
|
60
|
72
|
|
Mms
|
g
|
149
|
218
|
|
Bl
|
Tm
|
19.3
|
26
|
|
Qms
|
|
14
|
17
|
|
Qes
|
|
0.77
|
0.49
|
|
Qts
|
|
0.73
|
0.48
|
|
Levc
|
mH
|
0.88
|
1.1
|
|
No
|
|
1.35%
|
2.22%
|
