Model
|
HY1024
|
HY1224
|
HY1524
|
|
MECHANICAL
SPECIFICATIONS
|
|
|
|
|
Overall diameter
|
mm
|
259
|
313
|
387
|
|
Bolt circle diameter
|
mm
|
246
|
297
|
372
|
|
Baffle cutout
diameter
|
mm
|
238
|
284
|
361
|
|
Depth
|
mm
|
114
|
128
|
146
|
|
Flange and Gasket
|
mm
|
12
|
12
|
15
|
|
Net weight
|
kg
|
3.2
|
5.6
|
9.3
|
|
Shipping box (single
carton box)
|
mm
|
285*285*165
|
340*340*180
|
420*420*215
|
|
ELECTRICAL
SPECIFICATIONS
|
|
|
|
|
Nominal
diameter
|
inch
|
10
|
12
|
15
|
|
Nominal impedance
|
Ω
|
8
|
8
|
8
|
|
DC resistance
|
Ω
|
5.2
|
5.2
|
5.2
|
|
Nominal power
handling (AES)
|
W
|
250
|
400
|
600
|
|
Program power handling
|
W
|
500
|
800
|
1200
|
|
Sensitivity
(1W/1m)
|
±
2dB
|
92
|
95
|
95
|
|
Frequency range
(-10dB max)
|
Hz
|
50-6K
|
40-3.8K
|
40-3.8K
|
|
Voice coil diameter
|
mm
|
50， 2inch
|
65，2.5inch
|
100, 4inch
|
|
Voice coil material
|
cu
|
EISV
|
AP
|
AP
|
|
Former material
|
|
TIL
|
TIL
|
TIL
|
|
Winding depth
|
mm
|
15
|
15.8
|
18.6
|
|
Plate
|
mm
|
8
|
8
|
10
|
|
Magnet
|
oz
|
40
|
70
|
100
|
|
Basket
|
|
Aluminium
|
Aluminium
|
Aluminium
|
|
THIELE
& SMALL PARAMETERS
|
|
|
|
|
Fo
|
|
|
Hz
|
51
|
44
|
45
|
|
Revc
|
Ω
|
5.2
|
5.2
|
6.4
|
|
Sd
|
M2
|
0.034
|
0.053
|
0.082
|
|
Vas
|
L
|
41.8
|
96
|
118
|
|
Cms
|
uM/N
|
245
|
240
|
120
|
|
Mms
|
g
|
40
|
54
|
102
|
|
Bl
|
Tm
|
11.2
|
14.5
|
18.6
|
|
Qms
|
|
4
|
7.6
|
7.5
|
|
Qes
|
|
0.57
|
0.4
|
0.53
|
|
Qts
|
|
0.5
|
0.38
|
0.5
|
|
Levc
|
mH
|
0.48
|
0.68
|
0.78
|
|
No
|
|
0.98%
|
1.90%
|
1.90%
|
