Model
|
HY1522
|
HY1823
|
|
MECHANICAL SPECIFICATIONS
|
|
|
|
Overall diameter
|
mm
|
414
|
485
|
|
Bolt circle diameter
|
mm
|
/
|
/
|
|
Baffle cutout
diameter
|
mm
|
339
|
418
|
|
Depth
|
mm
|
155
|
200
|
|
Flange and Gasket
|
mm
|
12
|
12
|
|
Net weight
|
kg
|
11.5
|
12.2
|
|
Shipping box (single
carton box)
|
mm
|
410*410*195
|
510*510*245
|
|
ELECTRICAL
SPECIFICATIONS
|
|
|
|
Nominal
diameter
|
inch
|
15
|
18
|
|
Nominal impedance
|
Ω
|
8
|
8
|
|
DC resistance
|
Ω
|
6
|
5.2
|
|
Nominal power
handling (AES)
|
W
|
600
|
800
|
|
Program power handling
|
W
|
1200
|
1600
|
|
Sensitivity
(1W/1m)
|
±
2dB
|
96
|
97
|
|
Frequency range
(-10dB max)
|
Hz
|
35-3.5K
|
30-2.5K
|
|
Voice coil diameter
|
mm
|
100， 4inch
|
100， 4inch
|
|
Voice coil material
|
cu
|
AP
|
AP
|
|
Former material
|
|
TIL
|
TIL
|
|
Winding depth
|
mm
|
19.8
|
19.8
|
|
Plate
|
mm
|
10
|
10
|
|
Magnet
|
oz
|
125
|
125
|
|
Basket
|
|
Aluminium
|
Aluminium
|
|
THIELE & SMALL PARAMETERS
|
|
|
|
Fo
|
|
|
Hz
|
42
|
38
|
|
Revc
|
Ω
|
6.2
|
6.2
|
|
Sd
|
M2
|
0.075
|
0.122
|
|
Vas
|
L
|
99.2
|
213.6
|
|
Cms
|
uM/N
|
122
|
100
|
|
Mms
|
g
|
114
|
174
|
|
Bl
|
Tm
|
24
|
24
|
|
Qms
|
|
8.9
|
10.5
|
|
Qes
|
|
0.327
|
0.46
|
|
Qts
|
|
3.15
|
0.44
|
|
Levc
|
mH
|
0.87
|
0.86
|
|
No
|
|
2.25%
|
2.45%
|
