Model
|
HY1203
|
HY1503
|
HY1803
|
|
MECHANICAL
SPECIFICATIONS
|
|
|
|
|
Overall diameter
|
mm
|
320
|
395
|
465
|
|
Bolt circle diameter
|
mm
|
301
|
372
|
445
|
|
Baffle cutout
diameter
|
mm
|
283
|
355
|
422
|
|
Depth
|
mm
|
136
|
152
|
200
|
|
Flange and Gasket
|
mm
|
10
|
21
|
14
|
|
Net weight
|
kg
|
6.7
|
11.6
|
12
|
|
Shipping box (single
carton box)
|
mm
|
345*345*185
|
420*420*200
|
495*495*250
|
|
ELECTRICAL
SPECIFICATIONS
|
|
|
|
|
Nominal
diameter
|
inch
|
12
|
15
|
18
|
|
Nominal impedance
|
Ω
|
8
|
8
|
8
|
|
DC resistance
|
Ω
|
5.5
|
5.3
|
5.3
|
|
Nominal power
handling (AES)
|
W
|
400
|
600
|
800
|
|
Program power handling
|
W
|
800
|
1200
|
1600
|
|
Sensitivity
(1W/1m)
|
±
2dB
|
94
|
95
|
96
|
|
Frequency range
(-10dB max)
|
Hz
|
45-3.5K
|
35-3K
|
35-2.5K
|
|
Voice coil diameter
|
mm
|
75， 3inch
|
100， 4inch
|
100， 4inch
|
|
Voice coil material
|
cu
|
AP
|
AP
|
AP
|
|
Former material
|
|
TIL
|
TIL
|
TIL
|
|
Winding depth
|
mm
|
17.5
|
20
|
20
|
|
Plate
|
mm
|
8
|
10
|
10
|
|
Magnet
|
oz
|
78
|
125
|
125
|
|
Basket
|
|
Aluminium
|
Aluminium
|
Aluminium
|
|
THIELE
& SMALL PARAMETERS
|
|
|
|
|
Fo
|
|
|
Hz
|
62
|
48
|
40
|
|
Revc
|
Ω
|
5.3
|
5.3
|
5.3
|
|
Sd
|
M2
|
0.053
|
0.09
|
0.145
|
|
Vas
|
L
|
37.8
|
86.3
|
160
|
|
Cms
|
uM/N
|
94
|
73
|
53
|
|
Mms
|
g
|
68
|
147
|
200
|
|
Bl
|
Tm
|
19
|
22.5
|
24.5
|
|
Qms
|
|
10.9
|
5.9
|
13.8
|
|
Qes
|
|
0.395
|
0.55
|
0.61
|
|
Qts
|
|
0.38
|
0.5
|
0.58
|
|
Levc
|
mH
|
0.41
|
0.92
|
0.65
|
|
No
|
|
1.25%
|
1.70%
|
2.90%
|
