Model
|
HY0802
|
HY1002
|
HY1202
|
HY1502
|
|
MECHANICAL
SPECIFICATIONS
|
|
|
|
|
|
Overall diameter
|
mm
|
210
|
210
|
311
|
389
|
|
Bolt circle diameter
|
mm
|
197
|
197
|
294
|
370.5
|
|
Baffle cutout
diameter
|
mm
|
181
|
181
|
283
|
351
|
|
Depth
|
mm
|
88
|
106
|
112.5
|
142
|
|
Flange and Gasket
|
mm
|
8
|
8
|
13
|
11
|
|
Net weight
|
kg
|
2.9
|
3.1
|
4.1
|
4.75
|
|
Shipping box (single
carton box)
|
mm
|
240*240*135
|
290*290*160
|
340*340*170
|
420*420*195
|
|
ELECTRICAL
SPECIFICATIONS
|
|
|
|
|
|
Nominal
diameter
|
inch
|
8
|
10
|
12
|
15
|
|
Nominal impedance
|
Ω
|
8
|
8
|
8
|
8
|
|
DC resistance
|
Ω
|
6.2
|
6.8
|
5.2
|
5.2
|
|
Nominal power
handling (AES)
|
W
|
200
|
250
|
300
|
400
|
|
Program power handling
|
W
|
400
|
500
|
600
|
800
|
|
Sensitivity
(1W/1m)
|
±
2dB
|
92
|
96
|
95
|
95
|
|
Frequency range
(-10dB max)
|
Hz
|
65-4.5K
|
65-4.5K
|
40-5.5K
|
45-3.5K
|
|
Voice coil diameter
|
mm
|
50, 2inch
|
50, 2inch
|
65, 2.5inch
|
75, 3inch
|
|
Voice coil material
|
cu
|
EISV
|
EISV
|
EISV
|
EISV
|
|
Former material
|
|
Kapton
|
Kapton
|
Kapton
|
Kapton
|
|
Winding depth
|
mm
|
15
|
15
|
15.2
|
15.8
|
|
Plate
|
mm
|
8
|
8
|
8
|
8
|
|
Magnet
|
oz
|
40
|
40
|
50
|
60
|
|
Basket
|
|
Aluminium
|
Aluminium
|
Aluminium
|
Aluminium
|
|
THIELE
& SMALL PARAMETERS
|
|
|
|
|
|
Fo
|
|
|
Hz
|
75
|
58
|
44
|
45
|
|
Revc
|
Ω
|
5.5
|
5.2
|
5.2
|
6.2
|
|
Sd
|
M2
|
0.021
|
0.032
|
0.055
|
0.055
|
|
Vas
|
L
|
11
|
84
|
120
|
130
|
|
Cms
|
uM/N
|
175
|
210
|
278
|
125
|
|
Mms
|
g
|
25
|
35
|
45
|
98
|
|
Bl
|
Tm
|
10.9
|
11.3
|
11.8
|
15.9
|
|
Qms
|
|
9.6
|
11
|
3.8
|
10.2
|
|
Qes
|
|
0.52
|
0.57
|
0.57
|
0.68
|
|
Qts
|
|
0.5
|
0.55
|
0.49
|
0.64
|
|
Levc
|
mH
|
0.45
|
0.5
|
0.57
|
0.68
|
|
No
|
|
0.89%
|
2.82%
|
1.72%
|
1.72%
|
