Model
|
HY1031
|
HY1231
|
HY1531
|
|
MECHANICAL
SPECIFICATIONS
|
|
|
|
|
Overall diameter
|
mm
|
265
|
313
|
388
|
|
Bolt circle diameter
|
mm
|
349
|
293
|
371
|
|
Baffle cutout
diameter
|
mm
|
235
|
283
|
360
|
|
Depth
|
mm
|
112
|
125
|
150
|
|
Flange and Gasket
|
mm
|
10
|
12
|
12
|
|
Net weight
|
kg
|
3.5
|
5.5
|
6.8
|
|
Shipping box (single
carton box)
|
mm
|
295*295*155
|
345*345*180
|
420*420*205
|
|
ELECTRICAL
SPECIFICATIONS
|
|
|
|
|
Nominal
diameter
|
inch
|
10
|
12
|
15
|
|
Nominal impedance
|
Ω
|
8
|
8
|
8
|
|
DC resistance
|
Ω
|
5.2
|
5.2
|
5.2
|
|
Nominal power
handling (AES)
|
W
|
250
|
400
|
450
|
|
Program power handling
|
W
|
500
|
800
|
900
|
|
Sensitivity
(1W/1m)
|
±
2dB
|
94
|
96
|
96
|
|
Frequency range
(-10dB max)
|
Hz
|
60-6K
|
35-4K
|
35-4K
|
|
Voice coil diameter
|
mm
|
50，2inch
|
75， 3inch
|
75，3inch
|
|
Voice coil material
|
cu
|
EISV
|
AP
|
AP
|
|
Former material
|
|
Kapton
|
TIL
|
TIL
|
|
Winding depth
|
mm
|
15
|
17
|
17
|
|
Plate
|
mm
|
8
|
8
|
8
|
|
Magnet
|
oz
|
40
|
60
|
78
|
|
Basket
|
|
Aluminium
|
Aluminium
|
Aluminium
|
|
THIELE
& SMALL PARAMETERS
|
|
|
|
|
Fo
|
|
|
Hz
|
62
|
53
|
39
|
|
Revc
|
Ω
|
5.2
|
5.2
|
5.2
|
|
Sd
|
M2
|
0.035
|
0.053
|
0.083
|
|
Vas
|
L
|
38
|
64
|
185
|
|
Cms
|
uM/N
|
213
|
160
|
190
|
|
Mms
|
g
|
30
|
55
|
86
|
|
Bl
|
Tm
|
10.1
|
16.2
|
16.6
|
|
Qms
|
|
7.6
|
8.5
|
7.8
|
|
Qes
|
|
0.58
|
0.37
|
0.42
|
|
Qts
|
|
0.54
|
0.35
|
0.4
|
|
Levc
|
mH
|
0.35
|
0.75
|
0.75
|
|
No
|
|
1.56%
|
2.50%
|
2.50%
|
