Model
|
PA15DS800
|
PA18DS1000
|
|
MECHANICAL
SPECIFICATIONS
|
|
|
|
Overall diameter
|
mm
|
393
|
460
|
|
Bolt circle diameter
|
mm
|
374
|
441
|
|
Baffle cutout
diameter
|
mm
|
353
|
423
|
|
Depth
|
mm
|
170
|
200
|
|
Flange and Gasket
|
mm
|
15
|
14
|
|
Net weight
|
kg
|
11.5
|
15
|
|
Shipping box (single
carton box)
|
mm
|
440*440*235
|
500*495*260
|
|
ELECTRICAL
SPECIFICATIONS
|
|
|
|
Nominal
diameter
|
inch
|
15
|
18
|
|
Nominal impedance
|
Ω
|
8
|
8
|
|
DC resistance
|
Ω
|
5.2
|
5.2
|
|
Nominal power
handling (AES)
|
W
|
800
|
1000
|
|
Program power handling
|
W
|
1600
|
2000
|
|
Sensitivity
(1W/1m)
|
±
2dB
|
94
|
95
|
|
Frequency range
(-10dB max)
|
Hz
|
35-3K
|
30-3K
|
|
Voice coil diameter
|
mm
|
100, 4inch
|
100, 4inch
|
|
Voice coil material
|
cu
|
AP
|
AP
|
|
Former material
|
|
TIL
|
TIL
|
|
Winding depth
|
mm
|
22
|
27.5
|
|
Plate
|
mm
|
12
|
15
|
|
Magnet
|
oz
|
200
|
200
|
|
Basket
|
|
Aluminium
|
Aluminium
|
|
THIELE & SMALL PARAMETERS
|
|
|
|
Fo
|
|
|
Hz
|
|
44
|
|
Revc
|
Ω
|
|
5.2
|
|
Sd
|
M2
|
|
0.121
|
|
Vas
|
L
|
|
130
|
|
Cms
|
uM/N
|
|
62
|
|
Mms
|
g
|
|
204
|
|
Bl
|
Tm
|
|
22.5
|
|
Qms
|
|
|
12.8
|
|
Qes
|
|
|
0.5
|
|
Qts
|
|
|
0.59
|
|
Levc
|
mH
|
|
1.68
|
|
No
|
|
|
1.73%
|
