Model
|
HY1034
|
HY1234
|
HY1534
|
|
MECHANICAL
SPECIFICATIONS
|
|
|
|
|
Overall diameter
|
mm
|
259
|
313
|
390
|
|
Bolt circle diameter
|
mm
|
246
|
297
|
398
|
|
Baffle cutout
diameter
|
mm
|
238
|
284
|
351
|
|
Depth
|
mm
|
112
|
135
|
168
|
|
Flange and Gasket
|
mm
|
10
|
14
|
12
|
|
Net weight
|
kg
|
4.1
|
5.4
|
7.3
|
|
Shipping box (single
carton box)
|
mm
|
290*290*160
|
340*340*180
|
430*430*210
|
|
ELECTRICAL
SPECIFICATIONS
|
|
|
|
|
Nominal
diameter
|
inch
|
10
|
12
|
15
|
|
Nominal impedance
|
Ω
|
8
|
8
|
8
|
|
DC resistance
|
Ω
|
5.2
|
6
|
6
|
|
Nominal power
handling (AES)
|
W
|
300
|
400
|
450
|
|
Program power handling
|
W
|
600
|
800
|
900
|
|
Sensitivity
(1W/1m)
|
±
2dB
|
93
|
96
|
96
|
|
Frequency range
(-10dB max)
|
Hz
|
50-4.5K
|
40-4K
|
35-4K
|
|
Voice coil diameter
|
mm
|
65，2.5inch
|
75，3inch
|
75，3inch
|
|
Voice coil material
|
cu
|
EISV
|
AP
|
AP
|
|
Former material
|
|
Kapton
|
Til
|
Til
|
|
Winding depth
|
mm
|
16
|
16
|
16
|
|
Plate
|
mm
|
8
|
8
|
8
|
|
Magnet
|
oz
|
50
|
60
|
78
|
|
Basket
|
|
Aluminium
|
Aluminium
|
Aluminium
|
|
THIELE
& SMALL PARAMETERS
|
|
|
|
|
Fo
|
|
|
Hz
|
63
|
48
|
42
|
|
Revc
|
Ω
|
5.2
|
6
|
6.2
|
|
Sd
|
M2
|
0.035
|
0.053
|
0.085
|
|
Vas
|
L
|
28.7
|
701.5
|
212
|
|
Cms
|
uM/N
|
140
|
176
|
192
|
|
Mms
|
g
|
44
|
60
|
88
|
|
Bl
|
Tm
|
13
|
16.7
|
16.5
|
|
Qms
|
|
9.1
|
8.6
|
10.6
|
|
Qes
|
|
0.54
|
0.34
|
0.51
|
|
Qts
|
|
0.51
|
0.33
|
0.47
|
|
Levc
|
mH
|
0.035
|
0.034
|
0.62
|
|
No
|
|
1.30%
|
2.26%
|
2.20%
|
